Single Screw Splice Lock for 33.7mm Tube, Internal Handrail Joiner, Zinc Plated


Price:
Sale price£4.90
Inc. Vat

Express UK Delivery (2 Working Days)

In stock, ready to ship

Trusted by Industry Professionals

Description

Join two lengths of 33.7mm tube end to end with a joint you can barely see. This zinc plated pressed steel connector slides inside the tube ends; tighten the expanding screw and it grips the inside of both tubes along its full length, giving a straight, flush, non-slip joint with no welding, no sleeve and nothing on the outside. The price shown is for one splice lock, with a minimum order of 10.

Dimension drawing of the single screw splice lock for 33.7mm tube, 96mm long

Why use a splice lock

Invisible joint. Everything is inside the tube, so the rail looks like one continuous length.

Straight and strong. When tightened it presses on the inside of the tube in four places along its whole length, holding both tubes in line.

No hot work. Join rails on site with a drill and a hex key, ideal where welding is not allowed or the rail is already painted or galvanised.

Goes in as one piece. The two halves stay together while you push it in, so nothing drops inside the tube.

Where it is used

Joining lengths of tube in handrails, guard rails and balustrade top rails; pedestrian barriers and street furniture; key clamp frames and any tubular structure where a neat joint matters.

Single or double screw?

This is the single screw version: 96mm long with one screw, so only one access hole is needed. Choose it for knee rails, short runs and lighter duty joints; for top rails and long spans the double screw version locks each tube separately.

Specifications

What you get One single screw splice lock, minimum order 10
Suits tube 33.7mm outside diameter (25NB, 1 inch)
Tube wall 2.6 to 4.0mm
Length 96mm
Section 26 x 19mm
Expanding screws 1 x M8 hex socket, 23mm long, supplied fitted
Material Pressed steel, zinc plated
Weight 0.13kg

Fitting

Cut both tube ends square and remove any burr. Drill one access hole for the hex key in one tube, 10mm from its end. Push the splice lock half way into that tube with the screw facing the hole, slide the second tube over the other half until the ends meet, then tighten the screw with a hex key through the hole. The screw expands the two halves against the inside of both tubes. Fill or plug the hole before painting.

All sizes

See all fittings in Handrails & Brackets.

Care

Once fitted the splice lock is sealed inside the tube. Paint or touch up the rail and the filled access holes as usual.

Frequently asked questions

Is the price for one splice lock?

Yes, one. The minimum order is 10.

Can it join two different tube sizes?

No. Both tubes must be the same outside diameter.

Will it fit 33.7mm scaffold tube?

Yes, if the wall is between 2.6 and 4.0mm, which covers standard 33.7mm steel tube.

Can it be used on a bend?

No. It joins straight tube end to end. For corners use a weld bend or a key clamp elbow.

Ordering and delivery

Order 10 or more online with Express UK Delivery. For a full handrail, call 01744 520 110 or email sales@industrialsuppliesco.co.uk and we will list the tube, joints and fittings you need.
