Description
Leaves, scrolls and beads on 16mm square bar. This cast collar is 125mm tall: two vases covered in raised leaves and scrolls, joined in the middle by a 13mm band of round beads that is 43mm across, with a 29mm top and a 38mm foot. A 16mm square hole slides over 16mm square bar, so a row of them at one height gives railings and gates a richly detailed band. The price shown is for one collar, with a minimum order of 10.
Why choose this collar
Leaf detail on square bar. Most leaf collars are made for round bar. This one has a square hole, so it suits square bar railings and will not turn.
Rich all round. The leaves and scrolls run right round both halves, and the beaded band adds a second layer of detail.
Good value for its size. At 125mm tall it gives the look of a large ornate collar at a mid-range price.
Ready to paint. It comes in a raw cast finish and takes the same primer and paint as the rest of the ironwork.
Where it is used
Front railings, side and garden gates, and balustrades made from 16mm square bar.
Specifications
| What you get | One collar, minimum order 10 |
|---|---|
| Material | Cast metal |
| Finish | Raw, unpainted |
| Height | 125mm |
| Widest point | 43mm at the beaded band |
| Top and foot | 29mm and 38mm |
| Hole | 16mm square |
| Suits bar | 16 x 16mm square |
| Weight | 0.28 kg each |
| Fixing | Slide on, then tack weld or bond |
How many do you need?
Count one collar per bar for a single band. A metre of railing in 16mm square bar at 115mm centres has about 9 bars, so 10 collars covers just over a metre.
Is this the right collar?
| You want | Choose |
|---|---|
| A leaf and bead collar on 16mm square bar | This collar |
| A fluted urn collar on 16mm square bar | Ornate fluted collar, 140mm |
| A teardrop pattern collar on 12mm square bar | Ornate teardrop collar, 120mm |
| A leaf sleeve on 16mm round bar | Ornate leaf sleeve collar, 120mm |
| A plain round knuckle on 16mm square bar | Round knuckle collar, 43 x 68mm |
| 16mm square bar to fit them on | 16mm mild steel square bar |
Fitting and care
Thread the collars onto the bars before the bars are fixed at both ends. Mark a level or raked line across the bars, slide each collar to the line and turn it so the leaves face the same way, then hold it with a small tack weld at each end, or a metal adhesive if you are not welding.
Wire brush and degrease, then prime with a metal primer and paint to match the rest of the ironwork. We do not recommend hot-dip galvanising for this collar, as cast parts can blister or crack in the zinc bath. Use a zinc-rich primer instead outdoors.
Frequently asked questions
Is the price for one collar?
Yes, it is for one collar, with a minimum order of 10. For a larger job, call us for a quantity price.
Will it fit 16mm round bar?
It will slide on, but it will turn and sit loose in the corners of the square hole. For round bar, see the leaf sleeve collar above.
Can I fit it to bars that are already welded in?
No. It is a solid casting, so it has to go on before the bar is fixed at both ends.
Can it be galvanised?
We do not recommend hot-dip galvanising for this part. Prime and paint it, or use a zinc-rich primer before your top coat.
Ordering and delivery
Order 10 or more online, with Express UK Delivery to your site and same-day dispatch on orders before 2pm, Monday to Friday. For a larger job, call 01744 520 110 or email sales@industrialsuppliesco.co.uk and we will confirm availability and delivery before you order.
