Description
A bold teardrop pattern for 12mm square bar. This cast collar is 120mm tall: two vases, each with a large raised teardrop loop and scrolls, joined in the middle by a plain 10mm band, with a 32mm top and a 37mm foot, 40mm at the widest. A 13mm square hole slides over 12mm square bar, so a row of them at one height gives staircases, fences and gates a strong period band. The price shown is for one collar, with a minimum order of 10.
Why choose this collar
Large pattern, easy to read. The big teardrop loops show up clearly from a distance, even on slim 12mm bar.
Will not turn on the bar. The square hole keeps every collar facing the same way. The hole sits on the diagonal, so the pattern faces the corners of the bar.
Good value for its size. At 120mm tall it gives the look of a large ornate collar at a mid-range price.
Ready to paint. It comes in a raw cast finish and takes the same primer and paint as the rest of the ironwork.
Where it is used
Staircase balustrades, low front fences, garden gates and Juliet balconies made from 12mm square bar.
Specifications
| What you get | One collar, minimum order 10 |
|---|---|
| Material | Cast metal |
| Finish | Raw, unpainted |
| Height | 120mm |
| Widest point | 40mm |
| Top and foot | 32mm and 37mm |
| Hole | 13mm square, set on the diagonal |
| Suits bar | 12 x 12mm square |
| Weight | 0.28 kg each |
| Fixing | Slide on, then tack weld or bond |
How many do you need?
Count one collar per bar for a single band. A metre of balustrade in 12mm square bar at 110mm centres has about 9 bars, so 10 collars covers about a metre.
Is this the right collar?
| You want | Choose |
|---|---|
| A teardrop pattern collar on 12mm square bar | This collar |
| A fluted urn collar on 12mm square bar | Ornate fluted collar, 130mm |
| A leaf and bead collar on 16mm square bar | Ornate leaf collar, 125mm |
| A smaller fluted knuckle on 12mm square bar | Fluted knuckle collar, 47 x 53mm |
| A square foot on 12mm square bar | Square foot collar, 38 x 38mm |
| 12mm square bars to fit them on | 12mm square plain bar picket |
Fitting and care
Thread the collars onto the bars before the bars are fixed at both ends. Mark a level or raked line across the bars, slide each collar to the line and turn it so the teardrops face the same way, then hold it with a small tack weld at each end, or a metal adhesive if you are not welding.
Wire brush and degrease, then prime with a metal primer and paint to match the rest of the ironwork. We do not recommend hot-dip galvanising for this collar, as cast parts can blister or crack in the zinc bath. Use a zinc-rich primer instead outdoors.
Frequently asked questions
Is the price for one collar?
Yes, it is for one collar, with a minimum order of 10. For a larger job, call us for a quantity price.
Will it fit 12mm round bar?
It will slide on, but it will turn and sit loose in the corners of the square hole. Choose a collar with a round hole for round bar.
Can I fit it to bars that are already welded in?
No. It is a solid casting, so it has to go on before the bar is fixed at both ends.
Can it be galvanised?
We do not recommend hot-dip galvanising for this part. Prime and paint it, or use a zinc-rich primer before your top coat.
Ordering and delivery
Order 10 or more online, with Express UK Delivery to your site and same-day dispatch on orders before 2pm, Monday to Friday. For a larger job, call 01744 520 110 or email sales@industrialsuppliesco.co.uk and we will confirm availability and delivery before you order.
