90 Degree Weld Bend for 26.9mm Tube, Mild Steel Elbow for Handrails, 2.3mm Wall


Price:
Sale price£4.90
Inc. Vat

Express UK Delivery (2 Working Days)

In stock, ready to ship

Trusted by Industry Professionals

Description

A neat, strong 90 degree change of direction in 26.9mm tube. This raw steel elbow butt welds between two lengths of 26.9mm (20NB) tube, giving a smooth curve the same size as the tube instead of a sharp mitre or a squashed hand-bent tube. The ends are bevelled ready to weld. The price shown is for one weld bend, with a minimum order of 10.

Size guide for the 90 degree weld bend: 26.9mm outside diameter, 2.3mm wall, 29.5mm centre to face

Why use a weld bend

No mitres, no kinks. Bending tube by hand flattens it, and mitred joints leave sharp corners. A weld bend keeps the full round section through the turn.

Tight turns. With 29.5mm from centre to face, it fits where a pipe bender cannot, such as the corner where a ramp handrail turns along a landing or returns to a wall.

Ready to weld. Square cut, bevelled ends line up with the tube and give a full-strength butt weld.

Finish it with the frame. Self colour steel takes paint, powder coat, galvanising or plating with the rest of the job.

Where it is used

Stair and ramp handrails, balustrade top rails, guard rails and protection barriers, street furniture, cycle stands and any tubular frame in 26.9mm tube.

Specifications

What you get One 90 degree weld bend, minimum order 10
Suits tube 26.9mm outside diameter (20NB, 3/4 inch nominal bore)
Angle 90 degrees
Wall thickness 2.3mm
Centre to face 29.5mm
Ends Square cut and bevelled for butt welding
Material Mild steel, self colour (unpainted)
Weight 0.06kg

Fitting

Cut the tube ends square and deburr them. Line the bend up with each tube, tack weld at three or four points, check the angle, then weld right round. Grind the welds flush and dress them smooth so the hand slides over the joint without catching. Prime and paint, powder coat or galvanise the finished frame.

Care

Raw steel will rust if left bare, so finish the frame soon after welding and touch up chips outdoors.

Frequently asked questions

Is the price for one bend?

Yes, one weld bend. The minimum order is 10.

Will it fit 26.9mm tube with a thicker wall?

Yes. The outside diameter matches all 26.9mm tube; the wall of the bend is 2.3mm, so the inside will step slightly on thicker tube, which makes no difference to an outside butt weld.

Can I make a U-turn or return?

Yes. Two 90 degree bends welded back to back make a 180 degree return, for example at the end of a handrail.

Do you have other sizes?

Yes: 90 degree bend for 21.3mm tube, 90 degree bend for 33.7mm tube, and more in Handrails & Brackets.

Ordering and delivery

Order 10 or more online with Express UK Delivery. For larger quantities call 01744 520 110 or email sales@industrialsuppliesco.co.uk.
