Description
Product Overview
This Premium 90° Weld Bend is specifically designed to suit 33.7mm outside diameter tubes, making it an essential component for various applications including handrailing, street furniture, protection barriers, and all types of tubular constructions.
Features
- Outside Diameter: 33.7mm
- Nominal Bore: 25mm
- Wall Thickness: 2.6mm
- Radius: 38mm
- Self-colour and prepared for welding
Benefits
The smooth streamlined finish of this weld bend allows for installation in any environment, whether the structure is painted, galvanised, polyester or powder coated, or even chrome plated. The design enables tight bends and curves, effectively resolving the issue of sharp mitred corners or distortion that can occur with traditional radiusing techniques.
Technical Specifications
| Specification | Measurement |
|---|---|
| Outside Diameter | 33.7mm |
| Nominal Bore | 25mm |
| Wall Thickness | 2.6mm |
| Radius | 38mm |
| weight | 0.11 kg |
| length | 33.7mm |
| width | 25.0mm |
| material | Mild Steel |
| material finish | Raw Steel |
Applications
Typical uses for this weld bend include:
- Handrailing
- Street furniture
- Protection barriers
- All types of tubular constructions
FAQ
1. Can this weld bend be used in outdoor installations?
Yes, the smooth finish allows for use in various environments including outdoor settings.
2. Is this weld bend easy to install?
Absolutely, the design facilitates easy welding with chamfered edges for a neat, safe joint.
3. What materials can this weld bend be used with?
The weld bend is compatible with structures that are painted, galvanised, polyester coated, powder coated, or chrome plated.
