Description
Product Overview
This Premium 90° Weld Bend is specifically designed to fit 88.9mm outside diameter tubes, featuring a robust steel construction that ensures durability and reliability in various applications.
Typical Uses
- Handrailing
- Street furniture
- Protection barriers
- All types of tubular constructions
Features and Benefits
- Self Colour: Prepared for welding, allowing for seamless integration into existing structures.
- Smooth Streamlined Finish: Suitable for installation in painted, galvanised, polyester, powder-coated, or chrome-plated environments.
- Efficient Design: Enables tight bends and curves, eliminating sharp mitred corners and distortion commonly seen in tubes.
- Permanent and Strong Joint: Provides a neat, safe, and permanent joint with chamfered edges for ease of welding.
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Outside Diameter | 88.9mm |
| Nominal Bore | 80mm |
| Wall Thickness | 3.2mm |
| Radius | 119mm |
| weight | 1.24 kg |
| length | 88.9mm |
| width | 80.0mm |
| material | Mild Steel |
| material finish | Raw Steel |
Technical Specifications
- Material: High-performance steel
- Finish: Self-colour, prepared for welding
FAQ
What is the purpose of using a weld bend?
A weld bend allows for smooth transitions in tubular constructions, reducing the risk of sharp corners and enhancing the structural integrity.
Can this weld bend be used outdoors?
Yes, the weld bend's durable steel construction makes it suitable for various environments, including outdoor applications.
Is it easy to weld?
Yes, the chamfered edges facilitate easy welding, ensuring a strong and permanent joint.
