Description
A clean, simple 316 stainless wall bracket for a 48.3mm handrail. The curved saddle is fixed, ideal for level runs along corridors, ramps and walls. It holds the rail centre 78mm off the wall, leaving room for a hand to wrap round the rail. Solid 316 marine-grade stainless steel with a satin finish, the grade to choose outdoors and near the coast. The price shown is for one bracket, with a minimum order of 5.
Why choose this bracket
Room for your hand. 78mm from wall to rail centre leaves about 54mm of clear space behind a 48.3mm rail.
Marine-grade steel. 316 stainless resists salt and pollution, for outdoor ramps, coastal buildings and pools.
Slim and tidy. A 12mm arm and a 60mm round wall plate keep the bracket discreet under the rail.
Where it is used
Level wall handrails in hospital and care home corridors, schools, offices and hotels; outdoor ramps and paths beside walls; swimming pools and leisure centres.
Specifications
| What you get | One handrail bracket, minimum order 5 |
|---|---|
| Suits handrail | 48.3mm outside diameter round tube |
| Wall to rail centre | 78mm |
| Saddle height | 70mm |
| Saddle | Fixed, curved, 62 x 25mm, 2 holes 6mm at 42mm centres |
| Wall plate | 60mm round, 5mm thick, 3 holes on 42mm centres |
| Arm | 12mm round bar |
| Material | 316 stainless steel, satin finish |
| Weight | 0.26kg |
| Fixings | Not included: choose wall fixings to suit your wall |
How many do you need?
Space brackets about 1m apart or closer, with one within about 300mm of each end of the rail.
| Handrail length | Brackets |
|---|---|
| Up to 2m | 3 |
| 3m | 4 |
| 4m | 5 |
| 6m | 7 |
Matching parts
- Handrail: 316 stainless tube 48.3 x 2.0mm, 3m
- Rail ends: 316 handrail end for 48.3 x 2mm tube
- For stairs: 316 adjustable bracket, saddle tilts to the pitch
- Indoors on a budget: 304 bracket for 48.3mm
Fitting
Mark the rail line on the wall, fix the end brackets first, string a line between them and fix the rest to it with three screws each. Lay the rail in the saddles and screw up through the two saddle holes into the rail.
Care
Clean the stainless after installation and wash it down regularly, more often near the coast. Remove any brown tea staining with a mild acid cleaner such as white vinegar, or a stainless steel cleaner, on a microfibre cloth.
Frequently asked questions
Is the price for one bracket?
Yes, one bracket. The minimum order is 5.
Can I use it on a stair?
The saddle is fixed for level runs. On stairs, the adjustable bracket tilts to the pitch.
Can I use it outdoors?
Yes. 316 is the stainless grade recommended outdoors and near the sea.
Are screws included?
No. Choose fixings to suit your wall.
Ordering and delivery
Order 5 or more online with Express UK Delivery. For a full handrail with tube, ends and brackets, call 01744 520 110 or email sales@industrialsuppliesco.co.uk and we will list everything you need.
