Description
A neat, strong 90 degree change of direction in 60.3mm tube. This raw steel elbow butt welds between two lengths of 60.3mm (50NB) tube, giving a smooth curve the same size as the tube instead of a sharp mitre or a squashed hand-bent tube. The ends are bevelled ready to weld. The price shown is for one weld bend, with a minimum order of 10.

Why use a weld bend
No mitres, no kinks. Bending tube by hand flattens it, and mitred joints leave sharp corners. A weld bend keeps the full round section through the turn.
Tight turns. With 76mm from centre to face, it fits where a pipe bender cannot, such as the corner where a ramp handrail turns along a landing or returns to a wall.
Ready to weld. Square cut, bevelled ends line up with the tube and give a full-strength butt weld.
Finish it with the frame. Self colour steel takes paint, powder coat, galvanising or plating with the rest of the job.
Where it is used
Stair and ramp handrails, balustrade top rails, guard rails and protection barriers, street furniture, cycle stands and any tubular frame in 60.3mm tube.
Specifications
| What you get | One 90 degree weld bend, minimum order 10 |
|---|---|
| Suits tube | 60.3mm outside diameter (50NB, 2 inch nominal bore) |
| Angle | 90 degrees |
| Wall thickness | 2.9mm |
| Centre to face | 76mm |
| Ends | Square cut and bevelled for butt welding |
| Material | Mild steel, self colour (unpainted) |
| Weight | 0.49kg |
Fitting
Cut the tube ends square and deburr them. Line the bend up with each tube, tack weld at three or four points, check the angle, then weld right round. Grind the welds flush and dress them smooth so the hand slides over the joint without catching. Prime and paint, powder coat or galvanise the finished frame. Finish open tube ends with 60.3mm end caps.
Care
Raw steel will rust if left bare, so finish the frame soon after welding and touch up chips outdoors.
Frequently asked questions
Is the price for one bend?
Yes, one weld bend. The minimum order is 10.
Will it fit 60.3mm tube with a thicker wall?
Yes. The outside diameter matches all 60.3mm tube; the wall of the bend is 2.9mm, so the inside will step slightly on thicker tube, which makes no difference to an outside butt weld.
Can I make a U-turn or return?
Yes. Two 90 degree bends welded back to back make a 180 degree return, for example at the end of a handrail.
Do you have other sizes?
Yes: 90 degree bend for 42.4mm tube, 90 degree bend for 76.1mm tube, and more in Handrails & Brackets.
Ordering and delivery
Order 10 or more online with Express UK Delivery. For larger quantities call 01744 520 110 or email sales@industrialsuppliesco.co.uk.
