Mechanical Code Lock for Sliding Gates, 50mm Box Section, Keypad Both Sides, Silver

This is a mechanical code lock for sliding gates made from 50mm box section, with a push-button keypad on both sides of the gate and a twisting catch bolt that hooks into a keep on the post as the gate closes. It needs no batteries, mains power or cabling, so any sliding gate can have keypad access control without an electrician. The silver aluminium case holds a stainless steel mechanism, the keypads have dust and rain covers, and a stainless collar around the catch bolt stops it being cut through. The price shown is for one lock with handles, cylinder and keys; the sliding gate keep for the post is sold separately.

Why use this lock

Made for sliding gates. The twisting catch bolt and its self-correcting keep pull the gate into line as it closes, so the lock engages cleanly even when a sliding gate does not stop in exactly the same place every time.

Code on both sides. There is a keypad on each face of the gate, and different entrance and exit codes can be used, so you control who comes in and who goes out.

No power, nothing to fail. Fully mechanical: no batteries to change and no wiring along the fence, so it keeps working on remote gates and in a power cut.

Codes set in minutes. Codes of four to six digits are quick to set up and change, the code resets after the handle is pushed, and an integrated press plate stops the code being found by feel.

Flexible fitting. The keep can be mounted horizontally or vertically to suit the post and the way the gate closes.

Where it is used

Pedestrian and light sliding gates at schools, business units, depots and utility compounds, car parks, sports grounds and blocks of flats, wherever a sliding gate needs code access without power.

Specifications

What else you need

Other sliding gate code locks

Choosing the right option

Match the lock to the box section of the sliding gate: this one is for 50mm box section. Choose silver for galvanised or silver gates and black for black gates. Order the stainless sliding gate keep for the post, which is designed to work with the twisting catch bolt. For swing gates, choose a swing gate code lock instead.

Fitting and care

Fix the lock to the closing end of the sliding gate with the fixings supplied, fit the handles and cylinder, then fit the keep on the post so the catch bolt engages fully as the gate closes, mounting it horizontally or vertically to suit. Set your codes following the instructions and test both sides with the gate open before closing. Keep the rain covers shut, wipe the case with warm soapy water and do not paint over the keypads or bolt.

Frequently asked questions

Ordering and delivery

Order online with Express UK Delivery and same-day dispatch on orders before 2pm, Monday to Friday. To check which lock and keep suit your gate, call 01744 520 110 or email sales@industrialsuppliesco.co.uk.
