Description
A weld-on eye guide for a 20mm drop bolt. A flat 6mm steel ring, 35mm across with a 22mm hole, on a 15mm tab and a small lug beside the ring, 64mm long overall. Weld two to the closing stile of a gate, one low and one higher up, and the bolt slides down through both rings into the ground. Plain steel, ready to paint or galvanise with the gate. The price is for one eye, minimum order 10.
Why choose this eye
Right clearance. The 22mm hole gives a 20mm bolt a little room, so it slides freely after painting.
Easy to weld. The flat tab sits square on the stile and takes a full weld down both edges.
Finish to match. Bare steel takes paint, powder coat or hot-dip galvanising with the rest of the gate.
Specifications
| Sold as | One eye, minimum order 10 |
|---|---|
| Length | 64mm overall |
| Ring | 35mm across, 22mm hole |
| Tab | 15mm wide |
| Lug | Small lug beside the ring, 9mm |
| Thickness | 6mm steel plate |
| Suits | 20mm drop bolts |
| Finish | Plain steel, paint or galvanise after welding |
| Fixing | Weld on |
| Weight | About 0.04 kg |
Which part do you need?
| You want | Choose |
|---|---|
| Eye for a 12mm bolt, round ring, 65mm | 12mm drop bolt eye |
| Eye for a 12mm bolt with lug, compact 50mm | 12mm drop bolt eye with lug |
| Eye for a 16mm bolt, round ring, 65mm | 16mm drop bolt eye |
| Eye for a 16mm bolt with lug, 6mm thick | 16mm drop bolt eye with lug |
| Eye for a 20mm bolt with lug, 6mm thick | This part |
| Hook to hold a 12mm bolt up | 12mm drop bolt hook |
| Hook to hold a 16mm bolt up | 16mm drop bolt hook |
| A 12mm bolt, two eyes and a hook in one pack | 12mm single drop bolt kit |
Fitting
Stand the bolt against the closing stile with its foot on the ground. Thread two eyes onto it and weld the first about 50mm above the bottom rail and the second 250 to 300mm higher, both lined up so the bolt slides freely. Add a drop bolt hook under the handle to hold the bolt up. Clean the welds and paint or galvanise with the gate.
