Description
A 16mm solid round steel bar with a 35mm ball welded on the top, 1.45m long. It is the classic ball-top upright for railings and gates: cut it to height at the bottom, weld it between the rails, and the row of balls gives the run a neat, traditional finish. The price shown is for one bar, with a minimum order of 5.
Why choose this bar
Ball already fitted. The 35mm ball is welded on, so there is no fitting or welding at the top and every upright matches.
Solid steel. A 16mm solid round bar, 2.41 kg each, strong enough for railings and gates that see real use.
Cut to height. At 1450mm long it can be cut down at the bottom to suit the height of your railing.
Safer than a spike. A round ball top looks smart without the sharp point of a spear head, so it suits gardens, schools and homes.
Where it is used
As the uprights in garden and front railings, gates, balustrades, fence infill and garden structures.
Specifications
| What you get | One bar, minimum order 5 |
|---|---|
| Material | Solid mild steel |
| Finish | Raw, unpainted |
| Bar | 16mm round |
| Ball | 35mm, welded on |
| Length | 1450mm overall |
| Weight | 2.41 kg each |
How many do you need?
Divide the length of the run by the gap you want between uprights. Railings are usually set at 100 to 125mm centres, which is 8 to 10 bars per metre. Keep the clear gap under 100mm where children could climb through.
Is this the right bar?
Thicker bar with a bigger ball suits taller, heavier railings; 12mm bar suits garden and front railings.
| Bar | Choose |
|---|---|
| 12mm bar, 20mm ball, 1.5m | 12mm bar with 20mm ball |
| 12mm bar, 25mm ball, 1.2m | 12mm bar with 25mm ball |
| 12mm bar, 30mm ball, 1.2m | 12mm bar with 30mm ball |
| 16mm bar, 35mm ball, 1.45m | This bar |
| 20mm bar, 40mm ball, 1.2m | 20mm bar with 40mm ball |
| Ball tops to weld on your own bar | Small cast ball post top |
Fitting and care
Mark the height on each bar and cut the bottom end square. Set the bars at even centres and weld them to the top and bottom rails, keeping the balls in a level line.
Wire brush and degrease, then prime with a metal primer and paint. If the railing is going for hot-dip galvanising, tell the galvaniser it is solid bar with a welded ball.
Frequently asked questions
Is the price for one bar?
Yes, it is for one bar, with a minimum order of 5.
Can I cut it shorter?
Yes. Cut it at the bottom end with a hacksaw, cut-off saw or grinder.
Is the bar solid?
Yes, it is 16mm solid round bar, 2.41 kg each.
Why is there rust on it?
It is raw steel with no coating, so light surface rust can form in storage. It wire brushes off before priming.
Ordering and delivery
Order 5 or more online, with Express UK Delivery to your site and same-day dispatch on orders before 2pm, Monday to Friday. For a larger job, call 01744 520 110 or email sales@industrialsuppliesco.co.uk and we will confirm availability and delivery before you order.
