Description
The top half of a made-to-measure handrail bracket. This small 4mm steel plate is curved along its length to sit snug under a 48.3mm round tube handrail. Weld a 12mm bar stem into the 12.5mm centre hole and screw or weld the plate to the underside of the rail through the two 6.5mm holes. With our L-shaped bracket stem and 75mm round backplate it makes a complete wall bracket. Plain mild steel, ready to weld and paint. The price shown is for one, with a minimum order of 10.
Why choose it
Fits the tube. The plate is saddled to the outside of 48.3mm tube, so it sits flat to the rail with no gaps to fill.
Takes a 12mm stem. The 12.5mm centre hole locates a 12mm round bar stem square for welding.
Two fixing holes. 6.5mm holes at 43mm centres take screws or rivets into the rail, or the plate can be welded on.
Make brackets to suit. Combine it with any stem length or wall plate to get the projection and height your job needs.
Where it is used
Wall handrails and stair rails in 48.3mm tube; made-to-measure brackets for schools, offices, flats and public buildings; repairs where an old bracket saddle has broken; general handrail fabrication.
Specifications
| What you get | One, minimum order 10 |
|---|---|
| Size | 63mm x 24mm, 4mm steel, 6.5mm deep when curved |
| Suits | 48.3mm outside diameter tube |
| Centre hole | 12.5mm, for a 12mm round bar stem |
| Fixing holes | 2 x 6.5mm at 43mm centres |
| Material | Mild steel, raw (self colour) |
| Weight | 0.04kg |
Fitting
Push a 12mm stem into the centre hole from the curved side so it stands square, and weld it on the flat side. Set the plate against the underside of the rail, drill through the two holes and fix with screws or rivets, or weld round the plate. Paint, powder coat or galvanise the finished bracket.
Related parts
- Plate for 42.4mm tube
- 75mm round backplate to weld the stem to
- L-shaped 12mm bracket stem, 75mm projection
See all fittings in Handrails & Brackets.
Care
Raw steel will rust if left bare, so paint, powder coat or galvanise after welding and touch up chips outdoors.
Frequently asked questions
Is the price for one plate?
Yes, one plate. The minimum order is 10.
Does it come with a stem?
No. Choose our L-shaped 12mm bracket stem, or use your own 12mm bar.
Is it galvanised?
No, it is plain mild steel so it welds cleanly. Galvanise or paint it after welding.
