Description
A small C scroll in 12 x 6mm plain flat bar, 115mm wide and 60mm high. The bar runs straight across the top, rounds down at each side and finishes in a tight curl turned inwards, each with a pointed tip, leaving a gap in the middle. The flat top is what sets it apart: it sits flush against a rail, so it is made for the decorative band near the top or bottom of a gate or railing, one scroll in each gap between the vertical bars. It is also used along a top rail as a cresting, and on furniture, fire screens and headboards. It comes in raw mild steel, ready to weld, then paint, powder coat or galvanise. The price shown is for one scroll, with a minimum order of 10.
Specifications
| Overall | 115mm wide, 60mm high |
|---|---|
| Bar | 12 x 6mm plain flat bar, on edge |
| Depth | 12mm |
| Shape | Straight flat top, a tight inward curl at each end with a pointed tip |
| Material | Mild steel |
| Finish | Raw steel, not painted |
| Weight | About 0.15 kg |
| Sold as | One scroll, minimum order 10 |
Why this scroll works
A flat top that sits flush. The straight top lies along a rail for its whole length, so it welds cleanly and looks deliberate rather than perched.
Sized for a bay. At 115mm wide it fills a 115mm gap between vertical bars, so one scroll per gap makes a neat repeating band; with 12mm bars that means bars at 127mm centres.
Two feet as well as a top. The two curls sit on the lower rail, so in a band it touches both rails and is held at three points.
Pointed tips. The tapered ends of the curls give a finished, forged look once painted.
Where it is used
- Decorative bands in gates and railings
- Cresting along a top rail
- Garden furniture and fire screens
- Headboards, brackets and signs
Will it fit my layout?
| Your layout | What works |
|---|---|
| A band between two rails | Rails about 60mm apart, inside face to inside face; flat top to the upper rail, curls on the lower rail |
| Between vertical bars | A clear gap of about 115mm between bars, one scroll per gap |
| On top of a rail | Stand it on its curls, or turn it over and weld the flat top to the rail |
| A slightly narrower gap | Close the scroll a little by hand before fitting, or see the smaller C scrolls below |
Fitting and finishing
Set out the band, drop a scroll into each gap and check they all sit square and the same way up. Tack each one at the top and at both curls, recheck, then weld fully.
Raw steel will rust outdoors. Clean off the mill scale, prime with a zinc-rich primer, working it into the curls, and top coat with a metal paint, or have the finished work hot-dip galvanised or powder coated.
Is this the right scroll?
| You want | Choose |
|---|---|
| A flat-topped C, 115 x 60mm | This scroll |
| A C scroll 100 x 60mm | C scroll 100 x 60mm |
| A C scroll 100 x 70mm | C scroll 100 x 70mm |
| A wider C, 150 x 75mm | C scroll 150 x 75mm |
Frequently asked questions
Is the price for one scroll?
Yes, the price is for one scroll and the minimum order is 10. For a full band of scrolls, call us for a quantity price.
Is it a structural part?
No. It is a decorative scroll. It adds detail and some stiffness between rails, but the gate or railing frame must carry the load.
Which way up does it go?
In a band the flat top usually goes to the upper rail with the curls below, but it looks just as good turned over with the curls on top.
Does it come painted?
No, it is raw steel so it welds cleanly. Paint, powder coat or galvanise it once it is fitted.
Ordering and delivery
Order online for Express UK Delivery, with same-day dispatch on orders placed before 2pm, Monday to Friday. For larger quantities, call 01744 520 110 or email sales@industrialsuppliesco.co.uk and we will confirm stock and delivery before you order.
