80mm Hollow Steel Hemisphere, Pressed Half Ball Dome Cap for 76mm Tube Posts and Bollards


Price:
Sale price£3.90
Inc. Vat

Express UK Delivery (2 Working Days)

In stock, ready to ship

Trusted by Industry Professionals

Description

A pressed steel half ball, 80mm across, the domed cap for 76.1mm round tube posts, bollards and gate posts. This hemisphere is pressed from mild steel sheet 2 to 3mm thick, 80mm across the open rim and about 40mm high, smooth on the outside and hollow underneath. Weld it over the open end of a round tube to seal it with a rounded dome, or weld two together to make an 80mm hollow ball. It weighs about 0.15 kg. The price shown is for one hemisphere, with a minimum order of 10.

Dimension drawing of the 80mm hollow steel hemisphere: 80mm across, 40mm high, wall 2 to 3mm, with cross-section

Why choose this hemisphere

Made for 76.1mm tube. The 80mm rim sits on the end of standard 76.1mm round tube with a small overhang to weld to, giving a smooth, finished dome.

Seals the post. A welded dome keeps rain out of bollards and gate posts, so they do not fill with water and rust from the inside.

Rounded and safe. A smooth dome has no sharp edges for people, cars or livestock.

Light and quick to fit. At about 150 grams it is easy to hold in place and tack, and the 2 to 3mm wall welds without burning through.

Where it is used

Car park and pavement bollards, field and farm gate posts, barrier and handrail posts, play equipment, sign posts, and small ball finials made from two halves.

Specifications

What you get One hemisphere, minimum order 10
Diameter 80mm across the open rim
Height About 40mm
Wall thickness 2.0 to 3.0mm
Construction Pressed, hollow, open underneath
Material Mild steel
Finish Raw, unpainted
Weight About 0.15 kg
Fixing Weld on

The height is measured from the side photo and rounded, so allow a millimetre or two either way.

Which tube does it suit?

Tube or post you are capping How the 80mm dome fits
76.1mm round tube Sits on the end with a slight overhang, weld all round, the best match
60.3mm round tube Too big, choose a 60mm dome
75mm or 80mm square box Weld a flat cap plate first, then the dome on top
88.9mm tube or larger Too small, choose a 100mm dome

Is this the right hemisphere?

You want Choose
An 80mm hollow half ball This hemisphere
A smaller hollow half ball 70mm hollow hemisphere
A larger hollow half ball 100mm hollow hemisphere
A ready-made 80mm hollow ball 80mm hollow sphere
A solid 80mm ball 80mm solid sphere
Every sphere and hemisphere All spheres and hemispheres

Fitting and care

Cut the tube square and remove the burr. Clean the rim and the tube end back to bright steel, sit the dome centred on the end, tack it at four points opposite each other, then weld round in short runs, keeping the heat down on the thin wall. Dress the weld with a flap disc for a smooth line.

Degrease, then prime with a zinc-rich or metal primer before painting. Hot-dip galvanising after welding gives the longest life outdoors; drill a small vent hole low down on the post so it galvanises safely.

Frequently asked questions

Is the price for one hemisphere?

Yes, it is for one half ball, with a minimum order of 10.

Is it solid?

No. It is a pressed shell 2 to 3mm thick, hollow and open underneath.

Will it fit 76.1mm tube?

Yes. The rim is 80mm across, so it sits on the end of 76.1mm tube with a little overhang to weld round.

Is it painted?

No. It is raw steel and will rust if left bare outdoors, so prime and paint it, or galvanise it, once it is welded on.

Can I make a full ball?

Yes. Weld two together rim to rim and grind the seam, or buy the ready-made 80mm hollow sphere.

Ordering and delivery

Order 10 or more online, with Express UK Delivery to your site and same-day dispatch on orders before 2pm, Monday to Friday. For a larger job, call 01744 520 110 or email sales@industrialsuppliesco.co.uk and we will confirm availability and delivery before you order.
