Description
Product Overview
This Premium Hydraulic 180° Gate Closer and Double Bearing Hinge is designed for maximum efficiency and durability. It features a patented self-closing mechanism that ensures smooth operation regardless of external temperatures. Suitable for gates weighing up to 150KG, this innovative solution offers adjustable force, closing speed, and final snap to meet your specific needs.
Key Features
- Self-closing hinge with patented hydraulic damping
- Adjustable closing speed & closing pressure for customizable operation
- Easy mounting with Quick-Fix system
- Adjustable freerun for perfect closing (final snap)
- Compatible with left and right opening gates
- Maximum opening angle of 180°
- Durable powder-coated aluminium casing
- Double stainless steel bearing for enhanced longevity
- 2-dimensional adjustability (2 x 20 mm)
- Easy to open with a maximum force of 15 Nm
- Conforms to regulations regarding maximum allowed forces for gate operation
- Ideal for use with magnetic and mechanical locks
- Includes bottom hinge for seamless integration
- Specifically designed for outdoor use, rain & frost-proof
- Aesthetic design suitable for various environments
- Burglar proof and anti-theft features
- Consistent closing force across the full 180° opening angle
- Closing speed remains unaffected by temperature changes
- Tested for gates up to 150 kg and max width of 1.2 m
- Endurance tested for 500,000 movements
- Functional at temperatures as low as -30° C
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Maximum Gate Weight | 150 kg |
| Maximum Width | 1.2 m |
| Temperature Resistance | -30° C |
| Tested Movements | 500,000 |
| Weight | 4.69 kg |
| Length | 400.0mm |
| Width | 110.0mm |
| Depth | 52.0mm |
Technical Specifications
- Material: Powder-coated Aluminium
- Bearings: Double stainless steel
- Adjustment Range: 2 x 20 mm
- Force Requirement for Opening: Max. 15 Nm
FAQ
Q: Can this gate closer be used for both left and right opening gates?
A: Yes, it is designed for compatibility with both left and right opening gates.
Q: What is the maximum weight capacity for the gate?
A: This gate closer supports gates weighing up to 150 kg.
Q: Is this product suitable for outdoor use?
A: Yes, it is specifically designed for outdoor applications and is rain and frost-proof.
